Item
|
specification
|
|
House
|
dimension 36CM*26CM*12CM（L*W*H） 8 usb ports
|
|
Screen size
|
7 inch LED
|
|
Screen Resolution
|
1024X600
|
|
Screen contrast
|
1000:01:00
|
|
Screen colur
|
16.2M
|
|
Screen brightness
|
250cd/㎡
|
|
Touch Screen
|
Capacitive touch screen
|
|
Morthboard
|
J1900 Industrial Motherboard
|
|
CPU
|
Intel Turbo Boost 2.42 GHZ double cores
|
|
RAM
|
DDR3 1600L 4GB
|
|
SSD
|
SSD 60G
|
|
Hard drive bay
|
One bay for inserting a hard disk
|
|
Hard disk
|
optional hard drive 2T /4T/ 6T /8T hard drive
|
|
Power
|
Industrial power supply output rating 85W
|
|
USB interface
|
10 usb ports HUB output current 1.2A for every port
|
|
Ouside USB interface
|
2 USB2.0 ports
|
|
Audio
|
ALC662 chip，supply 6 channel output
|
|
Speaker
|
two 8 OHM 3W speaker
|
|
Lan interface
|
Onboard Realtek RTL8111F 1000M Lan card
|
|
WIFI
|
Intel 5100 Wifi module，6dbWifi antenna
|
|
Work temperature
|
subzero 20 ---+80 degree temperatures,
|
|
Storage Temperature
|
subzero 20℃——60℃
|
|
Storage Humidity
|
Humidity：10%~90%
|
|
Lan cable
|
RJ45 100M cable
|
|
Power cable
|
Optional power cable: China standard, European standard, American Standard, British Standard
|
|
Power supply
|
AC power source 110-220V AC
|
|
Operation system
|
Default optional XP/Win8/Win10 the system Win7 system
|
|
Docking station system
|
Optional installation docking station system
|
