Item
|
Parameter
|
|
OS
|
Linux
|
|
Language
|
Chinese/English/Customized
|
|
Video Compression
|
H.264
|
|
OSD
|
Overlays information such as date time and vehicle ID
|
|
GUI
|
Graphical User Interface
|
Setup system parameters with the remote control.
|
|
Video Record System
|
Video Input
|
4CH AHD input,CVI,TVI or CVBS
aviation connector, 1.0Vp-p, 75Ω
|
|
Video Output
|
1 CVBS, 1.0Vp-p, 75Ω,Aviation,Support 1CH Full Screen,
4CH Screen
|
|
Preview
|
Support 1 channel and 4 channels preview.,Support Manual
/Alarm Trigger full screen preview
|
|
Resolution
|
1080P/720P/D1/HD1/CIF, MAX:4 channels of 1080P
|
|
Video Quality
|
0-7 levels, 0 is the highest level.
|
|
Video Standard
|
PAL: 100f/s , CCIR625 line,50field;
NTSC: 120f/s, CCIR525 line,60field;
CIF: 256Kbps ~ 1.5Mbps, 8 level video quality optional;
HD1: 600Kbps ~ 2.5Mbps, 8 level video quality optional;
D1: 800Kbps ~ 3Mbps, 8 level video quality optional;
720P: 4Mbps-6Mbps, multi level video quality optional
1080P:4Mbps-8Mbps,multi level video quality optional
|
|
Record Mode
|
The default setting is auto recording after power on.
Timed recording,
alarm trigger recording and manual recording are supported.
|
|
Audio
|
Audio Input
|
4CH ,Aviation Plug
|
|
Audio Output
|
1CH,Aviation Plug
|
|
Compression
|
G.726 compression, 8KB/s speed
|
|
Alarm Input
|
6Ch Alarm Input, kinds of alarm linkage support
|
|
Alarm Output
|
2CH Alarm Output
|
|
Position
|
Support Built GPS/BD Module
|
|
Interface
|
2CH RS232 to connect OBD, POS/Fuel Sensor/LED Advertisement Connection
|
|
1CH 485 Interface,Connect PTZ Camera
|
|
G-Sensor
|
Support G-sensor
|
|
Storage
|
SD
|
Dual SD Card,each max 128GB SD Card loop recording
|
|
Upgrade
|
Support SD Card updating
|
|
File Format
|
H.264
|
|
File System
|
Special FAT32 File System
|
|
Video Playback
|
Video Search
|
Search By Record Time/Record Type etc
|
|
Playback
|
Max support 4CH Replay /Stop/Fast/Slow at same time
|
|
Support forward and backward play
at the speed of: x 2,x4,x8,x16.
|
|
Voltage &
Power
|
Power Management
|
Wide Voltage.Support Timed/Delay off
|
|
Voltage Input
|
DC:+10V ~ +36V
|
|
Voltage Output
|
+12V@2.5A,+5V@2.5A
|
|
|
Power Consumption
|
Normal Working ＜5W
|
|
|
Working Environment
|
Temperature
|
-20℃ to +70℃
|
|
|
Humidity
|
20% to 80%
|
|
|
Security
|
Password
|
User/Admin 2 Level Different Password
|
|
|
others
|
Size
|
150(W) x57(H) x168(D) mm
|
|
|
Net Weight
|
1.1kg
|
|
