Item
|
Parameter
|
|
OS
|
Linux
|
|
Language
|
English/Chinese/Customized
|
|
Video Compression
|
H.264 Compression
|
|
OSD
|
Overlays information such as date time and vehicle ID
|
|
GUI
|
Graphical User Interface
|
Setup system parameters with the remote control.
|
|
Video Record
System
|
Video Input
|
8CH AHD input,CVI,TVI or CVBS
aviation connector, 1.0Vp-p, 75Ω
|
|
Video Onput
|
1 CVBS, 1.0Vp-p, 75Ω,Aviation,Support 1CH Full Screen,4CH Screen view
|
|
Preview
|
Support 1 channel and 4 channels preview.,
Support Manual/Alarm Trigger full screen preview
|
|
Resolution
|
1080P/720P/D1/HD1/CIF, MAX:8 channels of 1080P
|
|
Image Quality
|
0-7 levels, 0 is the highest level.
|
|
Video Standard
|
PAL: 100f/s , CCIR625 line,50field;
NTSC: 120f/s, CCIR525 line,60field;
CIF: 256Kbps ~ 1.5Mbps, 8 level video quality optional;
HD1: 600Kbps ~ 2.5Mbps, 8 level video quality optional;
D1: 800Kbps ~ 3Mbps, 8 level video quality optional;
720P: 4Mbps-6Mbps, multi level video quality optional
1080P:4Mbps-8Mbps,multi level video quality optional
|
|
Record Mode
|
The default setting is auto recording after power on.
Timed recording, alarm trigger recording and manual recording are supported.
|
|
Audio
|
Audio Input
|
8CH Aviation Plug Input
|
|
Audio Output
|
2CH,headphone connect at front panel, BNC Connect on Back panel
|
|
Compression
|
G.726 compression, 8KB/s speed
|
|
Alarm Input
|
6CH Alarm Input,1CH AD Input,impulse speed input,Alarm Linkage
|
|
Alarm Output
|
2CH Alarm Output,Support Light/Sound alarm sensor,Oil/Power cut off
|
|
Interface
|
2CH RS232 to connect OBD, POS/Fuel Sensor/LED Advertisement Connection
|
|
1CH 485 Interface,Connect PTZ Camera
|
|
Wireless Transmission
|
Support Built in 3G transmission,, WCDMA, CDMA2000,GPRS, EDGE;
Built in 4G module optional, TDD-LTE, FDD-LTE
|
|
GPS Position
|
Support Built GPS/BD Module
|
|
|
HDD
|
Max 2.5” 2TB HDD
|
|
Storage
|
SD Card
|
Max 128GB SD Card Mirror Recording Keep Data Safety
|
|
Update
|
Support USB Updating, SD Card Updating,OTA Remote Updating
|
|
File Format
|
H.264
|
|
File System
|
Special FAT32 File System
|
|
|
USB
|
USB Interface on Front Panel for data back up by U Disk,Hard Disk
|
|
Record Replay
|
Video Search
|
Search By Record Time/Record Type etc
|
|
Playback
|
Max support 4CH Replay /Stop/Fast/Slow at same time
|
|
Support forward and backward play at the speed of: x 2,x4,x8,x16.
|
|
Security
|
User/Admin 2 Level Different Password
|
|
Optional Functions
|
Voice Call
|
Support voice call each other
|
|
TTS Voice Broadcast
|
Support TTS voice broadcast function.
|
|
Serial Expand
|
Support LED Advertisement Panel,Oil Sensor,
POS,Bus Station Broadcaster,Car OBD,ect.external device
|
|
Voltage & Power
|
Power Management
|
Wide Voltage.Support Timed/Delay off
|
|
Input Voltage
|
DC:+10V - +36V
|
|
Output Voltage
|
+12V~1.5A,+5V~1.5A
|
|
Power
|
Working <5W
|
|
Working Environment
|
Temperature
|
-20℃ - +70℃
|
|
Humidity
|
20% - 80%
|
|
Ohters
|
Size
|
218 (D)* 161(W)* 65(H) mm
|
|
Net Weight
|
2.2 Kg
|
